8. Synchronizer

Sync CLI 🔁

The Sync CLI manages framework versions, migrations, and releases across all repositories in the dynatrace-wwse organization. One tool to keep every repo up to date.

Overview#

The Sync CLI runs from the codespaces-framework directory and operates on repos listed in repos.yaml. It follows a local-first workflow: repos are cloned locally, changes are made on branches, then pushed as PRs.

cd codespaces-framework
PYTHONPATH=. python3 -m sync.cli <command> [options]

Full Release Cycle#

The workflow for updating all repos to a new framework version:

graph LR
    A[Release] --> B[Push Update]
    B --> C[Monitor PRs]
    C --> D[Merge]
    D --> E[Tag + Release]
    E --> F[Cleanup]

Step 1: Release a new framework version#

Make your changes to the framework, commit them, then release:

# Bump the patch component, tag, push, create a GitHub Release
sync release --part patch

This creates a git tag on codespaces-framework, updates the default version in cli.py, and creates a GitHub Release with a categorized changelog (features, fixes, docs, maintenance).

To create a release for an existing tag without bumping:

sync release

Step 2: Push updates to all repos#

# Preview what would change
sync push-update --framework-version <version> --dry-run

# Execute: pull main → branch → full migrate → commit → push → PR
sync push-update --framework-version <version>

# --framework-version is optional: omitted, it targets the latest git tag
sync push-update --dry-run

Per repo, push-update:

📥 Clones if not present locally
🔄 Checks out main and pulls latest
🌿 Creates branch sync/framework-<version>
🔧 Runs full migration (Category A cleanup, templates, mkdocs, .env, README badges, devcontainer.json fixes)
📝 Commits all changes
🚀 Pushes branch and creates PR

On failure at any step, the branch is left in place for manual intervention.

To re-push changes at the same version (e.g. after fixing badges or templates):

sync push-update --framework-version <version> --force

Step 3: Monitor CI and merge#

# List all open PRs with CI status
sync list-pr

# Filter to sync PRs for a specific version
sync list-pr --framework-version <version>

# Merge passing PRs
sync list-pr --merge

# Close old PRs that are superseded
sync list-pr --framework-version <previous-version> --close -c "Superseded by <version>"

Step 4: Tag consumer repos and create releases#

After all PRs are merged:

# Preview
sync tag --framework-version <version> --bump patch --release --dry-run

# Create combined version tags + GitHub Releases
sync tag --framework-version <version> --bump patch --release

Each repo gets a tag of the form v<framework-version>_<repo-version> and a GitHub Release with categorized changelog.

Step 5: Cleanup#

# Delete merged branches (local + remote)
sync cleanup-branches

# Verify everything is clean
sync validate

Migration: What Happens#

When push-update or migrate runs on a repo, it executes these phases:

Phase	Action
1. Audit	Identifies Category A files and validates `devcontainer.json`
1b. Fix devcontainer.json	Moves an exact `shinojosa/dt-enablement:v1.0`…`v1.3.2` image to `FRAMEWORK_IMAGE` (`v1.4.0`: v1.3.2's Node 22.23.4 / ENH-075 entrypoint fix + base refresh, libbrotli1 USN-8956-1, docker CLI 28.5.2 — #205). Any other image (custom, scenario, another tag) is left as is. `--dry-run` reports, writes nothing
2. Clean Category A	Removes framework-owned files (now pulled from cache). Inside `.devcontainer/apps`, `p10k` and `yaml` only a path the framework ships or has ever shipped is removed, plus generated output (`gen/`, `*-gen.yaml`); a repo's own files there (e.g. `yaml/dt-tokens.yaml`, `yaml/dynakube-config.yaml`, `yaml/otel-collector.yaml`) are kept (1.19.1)
3. Thin Makefile	Installs wrapper that delegates to cached `makefile.sh`
4. source_framework.sh	Installs/updates versioned pull mechanism
5. mkdocs.yaml	Converts to `INHERIT: mkdocs-base.yaml` pattern
6. overrides/main.html	Parameterizes RUM snippet, extracts URL to mkdocs.yaml
7. deploy-ghpages.yaml	CI fetches `mkdocs-base.yaml` at framework version
8. .gitignore	Adds cache, mkdocs-base, generated-file (`/gen/.yaml`, `**-gen.yaml`), Dockerfile.framework entries
9. .env location	Moves from `runlocal/.env` to `.devcontainer/.env`
10. README badges	Updates branding, adds missing badges, fixes integration test link

All Commands#

Run sync <command> --help for the authoritative flags — the table below lists what each command is for, not every option it takes.

Migration & Updates#

Command	Description	Example
`push-update`	Full workflow: pull → branch → migrate → push → PR	`sync push-update --framework-version <version>`
`diff`	Preview what `push-update` would change, without touching git	`sync diff`
`migrate`	Migrate repos to the versioned pull model	`sync migrate --dry-run`
`migrate-mkdocs`	Convert a single repo's `mkdocs.yaml` to the `INHERIT` pattern	`sync migrate-mkdocs --repo <owner/name>`
`revert`	Undo uncommitted changes	`sync revert --repo template`
`validate`	Check `repos.yaml` schema and local repo state, including docs structure and the training's `delivery` front matter	`sync validate`
`check-delivery`	Check one training checkout's `.devcontainer/delivery.yaml` or `delivery` front matter; exit 1 when invalid (see Training delivery)	`sync check-delivery path/to/repo`

Versioning & Releases#

Command	Description	Example
`release`	Tag framework, create GitHub Release	`sync release --part patch`
`tag`	Tag consumer repos with the combined version	`sync tag --framework-version <version> --bump patch --release`
`bump-repo-version`	Bump only a repo's own version component	`sync bump-repo-version --repo <owner/name> --part minor`

Repository Management#

Command	Description	Example
`clone`	Clone repos from `repos.yaml`	`sync clone --all`
`checkout`	Check out `main` across repos and show status	`sync checkout --pull`
`protect-main`	Enable branch protection on the default branch	`sync protect-main --dry-run`
`cleanup-branches`	Delete merged branches (local + remote)	`sync cleanup-branches --dry-run`

Monitoring#

Command	Description	Example
`list-pr`	List PRs, approve, merge, or close	`sync list-pr --merge`
`list-issues`	List open issues	`sync list-issues --label bug`
`ci-status`	Latest CI run status across repos	`sync ci-status`
`status`	Show version drift	`sync status`
`list`	List registered repos	`sync list --sync-managed --json`

Registry generation#

Command	Description	Example
`generate-registry`	Build the registry consumed by The Hub	`sync generate-registry`
`generate-json`	Emit `repos.json` for the published catalog	`sync generate-json`

protect-main resolves the branch and the required check

It reads the default branch from the GitHub API rather than assuming main, accepts repos that are not in repos.yaml via --repo, and takes --check (repeatable) to set which status-check contexts are required. The default context is the integration-test job name — see Testing.

Common Recipes#

First-time setup#

sync clone                    # Clone all repos locally
sync validate                 # Check current state
sync migrate --dry-run        # Preview migration

Deploy a framework update#

sync release --part patch                          # bump + tag + GitHub Release
sync push-update --framework-version <version>         # Create PRs
sync list-pr --framework-version <version>             # Monitor CI
sync list-pr --merge                               # Merge passing
sync tag --framework-version <version> --bump patch --release  # Tag + release
sync cleanup-branches                              # Clean up

Fix something and re-push at the same version#

# Edit the framework, commit
sync push-update --framework-version <version> --force

Close old PRs#

sync list-pr --framework-version <previous-version> --close -c "Superseded by <version>"

Housekeeping#

sync protect-main              # Protect main on all repos
sync cleanup-branches          # Delete stale branches
sync list-issues               # Check for open issues

Key Files#

File	Purpose
`sync/cli.py`	CLI entry point
`sync/core/repos.py`	`repos.yaml` parsing, `RepoEntry` dataclass
`sync/core/version.py`	Version parsing and bumping
`sync/core/github_api.py`	GitHub API via `gh` CLI
`sync/core/local_git.py`	Local git operations
`sync/commands/migrate.py`	Migration logic, file classification, templates
`sync/commands/push_update.py`	Local-first push-update
`sync/commands/release.py`	Framework release with changelog
`sync/commands/tag.py`	Consumer repo tagging + releases
`sync/commands/list_pr.py`	PR listing, approve, merge, close
`repos.yaml`	Registry of all repos
`sync/tests/`	The CLI's own pytest suite — see Testing

Run the tests before changing sync/ or repos.yaml

The suite covers repos.yaml parsing, version maths and every subcommand, and it needs no network — but no GitHub Actions workflow runs it, so a regression only shows up if you run it:

pip install -r requirements-dev.txt
pytest sync/tests

Command Scope#

Command	Repos it operates on
`push-update`, `migrate`, `revert`, `tag`	sync-managed only (consumer repos)
`list-pr`, `list-issues`, `protect-main`, `cleanup-branches`	all active repos (including framework, website, tracker)
`clone`	sync-managed by default, `--all` for everything
`release`	framework repo only

Continue to Testing →

Training delivery#

A training declares how it may be delivered in the front matter of its docs/index.md (the docs_dir from mkdocs.yaml, if set), next to the catalog fields description, tags, difficulty and duration:

---
description: "Build your own observability agent"
tags: [interactive]
delivery:
  availability: workshop-only   # self-service (default) | workshop-only
  tenancy: single               # any (default) | single | multi
---

Field	Values	Meaning
`availability`	`self-service` (default), `workshop-only`	`self-service` can be started by a learner on their own; `workshop-only` only inside a workshop
`tenancy`	`any` (default), `single`, `multi`	how a workshop seats learners: all on the workshop's tenant (`single`), each on their own (`multi`), or the trainer chooses (`any`)

No block at all is valid and means self-service, tenancy any — what every training did before this field existed. A block that is present but wrong (an unknown key, a misspelt value) is refused, because silently falling back to the default would make the training self-service.

Shared infrastructure is not declared. A training has it when it ships .devcontainer/workshop-post-create.sh. Such a training must declare availability: workshop-only and tenancy: single — multi-tenant shared infrastructure is not supported yet. A workshop-post-start.sh without the create script is refused too.

sync check-delivery and sync validate enforce these rules. Orbital applies the same rules at runtime (shared/delivery.py mirrors sync/core/delivery.py, case for case).

`.devcontainer/delivery.yaml` (ENH-163)#

One file, next to the workshop scripts, that says how the training is delivered. When it exists it wins over the index.md block.

version: 1                   # required
type: same-tenant            # same-tenant | multi-tenant   (tenancy single | multi)
availability: workshop-only  # workshop-only | self-service (default self-service)
seats:
  personal: false            # learners get a personal environment
                             # (default true; false for a shared training)
  mode: full                 # full | dtctl-only (default full)
shared:                      # only with .devcontainer/workshop-post-create.sh
  instance: m6a.4xlarge      # the shared machine's shape (default: Orbital's setting)

Unknown keys and bad values are refused, as for the block.
With workshop-post-create.sh the file must say type: same-tenant and availability: workshop-only; seats.personal: true is refused until learners can have a seat beside a shared machine. A shared: block without the script is refused.
Both the file and an index.md block: disagreeing on availability or tenancy is refused (two truths); agreeing passes with a warning to remove the block.
shared.instance is checked by Orbital at booking against its allowlist (workshop_shared_instance_allowlist, default m6a.2xlarge, m6a.4xlarge, r6a.2xlarge, r6a.4xlarge), its ceiling (workshop_shared_instance_max_mb, default 131072 MiB) and its capacity table. A shape outside them refuses the booking with shared_instance_not_allowed — never a silent fallback. The lint here checks only the shape's form; the allowlist is Orbital's, read when the workshop is booked.

Moving every training to the file, and later refusing the index.md block, are separate steps.
